Deskripsi
LIHAT BROSUR : Brosur Total Station Topcon GM 55 52 Series
Total Station Topcon GM 55 memiliki akurasi 5 detik yang dapat mengukur dengan baik dan juga akurat. Kemudian di lengkapi dengan laser untuk pengukuran lebih presisi, bluetooth untuk transfer data, serta layar untuk menampilkan informasi pengukuran.
Alat ini mampu mengukur jarak 500 meter tanpa menggunakan prisma (reflectorless) dan jarak 4 km dengan bantuan prisma. Tersedia memori yang mampu menyimpan hingga 50.000 point, daya baterai kuat hingga 14 jam pemakaian serta sudah bersertifikasi IP66 yang tahan terhadap air dan juga debu.
Spesifikasi Total Station Topcon GM 55
- Akurasi 5 Detik
- Laser
- 1 Display
- Daya tahan baterai 14 jam
- Bisa menggunakan flashdisk max 32 GB
- USB 2.0
- Bluetooth
- Reflectorless 0,3 meter sampai 500 meter
- Reflective sheet 1,3 meter sampai 500 meter
- Mini prisma 1,3 meter sampai 500 meter
- One Prisma 1,3 meter sampai 4000 meter
Telescope
- Magnification / Resolving power | 30x / 2.5
- Others | Length : 171mm (6.7in.),x
- Objective aperture : 45mm (1.8in.) (48mm (1.9in.) for EDM),
- Image: Erect,
- Field of view: 1°30′ (26m/1,000m),
- Minimum focus: 1.3m (4.3ft.)
- Reticle illumination: 5 brightness levels
Angle Measurement
- Minimum Display (selectable) | 1”/5” (0.0002 / 0.001gon, 0.005 / 0.02mil)
- Accuracy (ISO 17123-3:2001) | 5″
- Dual-axis compensator | Dual-axis liquid tilt sensor,
- working range: ±6′
- Collimation compensation | On/Off (selectable)
Distance Measurement
- Laser output*1 | Reflectorless mode : Class 3R / Prism/sheet mode : Class 1
- Measuring range(under average conditions*2)
- Reflectorless*3 | 0.3 to 500m (1,640ft.)
- Reflective sheet*4*5 | RS90N-K: 1.3 to 500m (4.3 to 1,640ft.),RS50N-K: 1.3 to 300m (4.3 to 980ft.),RS10N-K: 1.3 to 100m (4.3 to 320ft.)
- Mini prisms | 1.3 to 500m (4.3 to 1,640ft.)
- One prism | 1.3 to 500m (4.3 to 1,640ft.)
- Minimum Display |
- Fine / Coarse : 0.0001m (0.001ft. / 1/8 in.) / 0.001m (0.005ft. / 1/8 in.) (selectable)
- Coarse : 0.001m (0.005ft. / 1/8 in.) / 0.01m (0.02ft. / 1 in.) (selectable)
- Tracking / Road : 0.01m (0.02ft. / 1 in.)
- Accuracy*2(ISO 17123-4:2001)(D=measuring distance in mm)
- Reflectorless*3 | (2 + 2ppm x D) mm*6
- Reflective sheet*4*5 | (2 + 2ppm x D) mm
- Prism*7 | (1.5 + 2ppm x D) mm
- Measuring time*8
- Fine | 0.9s (initial 1.5s)
- Rapid | 0.6s (initial 1.3s)
- Tracking | 0.4s (initial 1.3s)
OS, Interface and Data Management
- Operating system | Linux
- Display / Keyboard | Graphic LCD, 192 x 80 dots, backlight : on/off (Selectable) / Alphanumeric keyboard / 28 keys with backlight
- Control panel location | On single face
- Data storage
- Internal memory | Approx. 50,000 points
- Plug-in memory device | USB flash memory (max. 32GB)
- Interface | Serial RS-232C, USB2.0 (Type A for USB flash memory)
- Bluetooth modem (option) | Bluetooth Class 1.5, Operating range: up to 10m
General
- Laser-pointer | Coaxial red laser using EDM beam
- Levels
- Graphic | 6’ (Inner Circle)
- Circular level (on tribrach) | 10′ / 2mm
- Plummet
- Optical | Magnification: 3x, Minimum focus: 0.5m (19.7in.) from tribrach bottom
- Laser (option) | Red laser diode (635nm±10nm), Beam accuracy: <=1.0mm@1.3m, Class 2 laser product
- Dust and water protection / Operating temperature | IP66 (IEC 60529:2001) / -20 to +60ºC (-4 to +140ºF)
- Size with handle | 183(W)x 174(D)x 348(H)mm (On single face)
- Instrument height | 192.5mm from tribrach mounting surface
- Weight with battery & tribrach | Approx. 5.1kg (11.3lb)
Power Supply
- Battery | Li-ion rechargeable battery BDC46C
- Operating time (20ºC)*9 | Approx. 14hours
Application program
- On board
- REM Measurement
- 3D Coordinate Measurement
- Resection
- Stake Out
- Topography Observation
- Offset Measurement
- Missing Line Measurement
- Surface Area Calculation
- Route Surveying
- Point to Line
- On board
Kelengkapan
- 2 Unit Alumunium Tripod
- 1 Unit Prisma Polygon
- 1 Unit Prisma Single
- 1 Unit Pole/stick
- 1 Unit Charger
- 1 Unit Batery
- 1 Unit Kabel Data
- 1 CD Software
- Sertifikat Kalibrasi
- Kartu Garansi
Layanan purna jual
- Garansi servis dan kalibrasi 1 tahun
- Gratis training alat
- Gratis pengiriman dan juga COD khusus Kota Batam dsk
